Embraer E-Jet Family

Embraer

ICAOE170IATA170
Embraer E-Jet Family aircraft
EmbraerEmbraer E-Jet Family
Photo: Kahvilokki · CC BY-SA 4.0 · Modified

Details

The Embraer E-Jet family is a series of narrow-body short- to medium-range twin-engine jet airliners developed by Brazilian aerospace manufacturer Embraer. Introduced in the early 2000s as the successor to the ERJ family, the E-Jets feature modern technology including fly-by-wire controls, advanced avionics, and significantly improved passenger comfort. The original family consists of four main variants in two size categories: the smaller E170 (70-80 seats) and E175 (78-88 seats), and the larger E190 (98-114 seats) and E195 (108-124 seats). Unlike the rear-mounted engines of the ERJ series, E-Jets feature underwing-mounted engines (GE CF34-8E for E170/E175, and CF34-10E for E190/E195). The E170/E175 share 95% commonality, as do the E190/E195, with 89% commonality between the two sub-families. The E-Jet family has been highly successful with over 1,900 aircraft delivered worldwide. A second-generation E2 family (E175-E2, E190-E2, E195-E2) featuring more efficient engines and improved aerodynamics entered service in 2018.

4

Variants

1,900

Built

Weightscompared to Airbus A318

MRW (Maximum Ramp Weight)

51,960kg
0
25k
50k
68k

MTOW (Maximum Takeoff Weight)

51,800kg
0
25k
50k
68k

MLW (Maximum Landing Weight)

44,000kg
0
25k
50k
56k

MZFW (Maximum Zero Fuel Weight)

40,900kg
0
25k
53k

Empty Weight

28,500kg
0
25k
40k

Capacitycompared to Airbus A318

Passenger Capacity

114passengers
0
100
132

86% of A318 maximum capacity

Crew

Total
5
Cockpit
2
Cabin
3

Dimensions

Length

36.2m

Wingspan

28.7m

Height

10.6m

Wing Area

92.5m²

Cabin Width

2.74m

Cabin Height

2.06m

Catalog Price

Base List Price

$46M USD

2015 catalog price

Note: Actual prices vary based on configuration, options, and negotiations. This represents the manufacturer's base catalog price.

Engine Specifications

Engine Count

2×

Engine Model

GE CF34-8E / CF34-10E

Thrust per Engine

82.3 kN(18502 lbf)

Fuel & Cargo

Fuel Capacity

13,280 L

Cargo Volume

22 m³

Production & History

Total Produced

1,900

Production Status

In production

Manufacturing Period

2002–present

First Flight

February 19, 2002

Entered Service

March 17, 2004
