Boeing 707-320B
Boeing Commercial Airplanes
About
The 707-320B put JT3D turbofans and an extended, re-profiled wing on the intercontinental airframe. Boeing tabulates it at two certified standards, 328,000 and 336,000 lb ramp; this row carries the higher of the two. A take-off weight of 335,000 lb is possible with wet thrust. The cruise speed, cruise Mach, range, ceiling, climb rate and take-off distance are EUROCONTROL's figures for the B703 type code rather than a certificate's: a type certificate states limits and weights, not cruise performance, and the source does not distinguish sub-variants. Cabin width and height are Boeing's own, from Boeing D6-58322, 707 Airplane Characteristics for Airport Planning, section 2.5, page 19: interior trim to trim 139.3 in (354 cm), 86.3 in (219.2 cm) floor to ceiling.
Weightscompared to Boeing 757-300
Capacitycompared to Boeing 757-300
Passenger Capacity
64% of 757-300 maximum capacity
Dimensions
Length
Wingspan
Height
Cabin Width
Cabin Height
Engine Specifications
Engine Count
4×
Engine Model
Pratt & Whitney JT3D
Fuel & Cargo
Fuel Capacity
90,290 L
Cargo Volume
50.16 m³
Production & History
Production Status
Out of production
